Reliable storage for data protection, file serving, and more.
Designed for Synology systems, Synology drives deliver consistent performance and unmatched reliability for your deployments.
Hardware Specifications |
||
---|---|---|
CPU |
||
CPU
|
CPU Model | AMD Ryzen V1780B |
CPU Quantity | 1 | |
CPU Core | 4 | |
CPU Architecture | 64-bit | |
CPU Frequency | 3.35 (base) / 3.6 (turbo) GHz | |
Hardware Encryption Engine | ||
Memory |
||
Memory
|
System Memory | 8 GB DDR4 ECC UDIMM |
Memory Module Pre-installed | 8 GB (8 GB x 1) | |
Total Memory Slots | 2 | |
Maximum Memory Capacity | 32 GB (16 GB x 2) | |
Notes |
|
|
Storage |
||
Storage
|
Drive Bays | 16 |
Maximum Drive Bays with Expansion Unit | 28 (RX1225RP x 1) | |
Drive Type (See all supported drives) |
|
|
Hot Swappable Drive* | ||
Notes | Compatible drives are mandatory. Please consult our compatibility list before purchasing hard drives. For more details, please refer to this article. | |
External Ports |
||
External Ports
|
RJ-45 1GbE LAN Port | 2 |
RJ-45 10GbE LAN Port | 1 | |
USB 3.2 Gen 1 Port | 2 | |
Expansion Port | 1 | |
Expansion Port Type | Mini-SAS HD | |
Notes | This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes. | |
PCIe |
||
PCIe
|
PCIe Expansion | 1 x Gen3 x8 slot (x4 link) |
Appearance |
||
Appearance
|
Form Factor (RU) | 3U |
Size (Height x Width x Depth) | 132.3 mm x 482 mm x 656.5 mm | |
Weight | 17.3 kg | |
Rack Installation Support* | 4-post 19" rack (Synology Rail Kit - RKS-02) | |
Notes | The rail kit is sold separately | |
Others |
||
Others
|
System Fan | 80 mm x 80 mm x 3 pcs |
Fan Speed Mode |
|
|
Easy Replacement System Fan | ||
Power Recovery | ||
Noise Level* | 49.6 dB(A) | |
Scheduled Power On / Off | ||
Wake on LAN / WAN | ||
Power Supply Unit / Adapter | 550 watts | |
Redundant Power Supply | ||
AC Input Power Voltage | 100 V to 240 V AC | |
Power Frequency | 50/60 Hz, Single Phase | |
Power Consumption* |
134.48 watts (Access) 50.81 watts (HDD Hibernation) |
|
British Thermal Unit |
459.17 BTU/hr (Access) 173.49 BTU/hr (HDD Hibernation) |
|
Notes |
|
|
Temperature |
||
Temperature
|
Operating Temperature | 0°C to 35°C (32°F to 95°F) |
Storage Temperature | -20°C to 60°C (-5°F to 140°F) | |
Relative Humidity | 5% to 95% RH | |
Certification |
||
Certification
|
|
|
Warranty |
||
Warranty
|
3-year hardware warranty, extendable to 5 years with EW202 or Extended Warranty Plus | |
Notes |
|
|
Environment |
||
Environment
|
RoHS Compliant | |
Packaging Content |
||
Packaging Content
|
|
|
Optional Accessories |
||
Optional Accessories
|
|
|
Notes | For multi-module memory configurations, all modules must be identical and share the same model number. Check the Product Manual of your Synology product for recommended memory configurations. |
RX1225RP | ||
3.5" SATA HDD
|
Plus Series |
|
Enterprise Series |
|
|
2.5" SATA SSD
|
Enterprise Series |
|
M.2 NVMe SSD
|
Enterprise Series |
|
|
||
|
||
RKS-02 |
RX1225RP | |
3.5" SATA HDD
|
|
Plus Series |
|
Enterprise Series |
|
2.5" SATA SSD
|
|
Enterprise Series |
|
M.2 NVMe SSD
|
|
Enterprise Series |
|
|
|
|
|
RKS-02 |
