SNV3400/3500 Series M.2 NVMe SSD

Supercharge I/O performance

Enterprise M.2 NVMe SSD for Synology NAS

SNV3400

SNV3400

M.2 2280 NVMe SSD, tailored for Synology NAS with built-in M.2 slots

SNV3500

SNV3500

M.2 22110 NVMe SSD, built for demanding cache deployments in Synology rackmount NAS

Durable SSD for demanding caching workloads

Synology SNV3000 series NVMe SSD is designed to handle tough caching workloads in a 24/7 multi-user environment. Its durable I/O performance boosts system responsiveness and speeds up handling of frequent access data, providing a streamlined storage experience while minimizing service disruptions to your Synology NAS.

Performance

Performance

Up to 70,000 4K random write IOPS1

Endurance

Endurance

988 TBW for 24/7 enterprise workload2

Analytics

Analytics

Actionable insight for optimal performance and longevity3

Updates

Updates

One-click drive firmware updates through DSM4

Consistently fast caching for 24/7 environments

Built for system cache, Synology SNV3000 series pushes up random I/O performance and reduces latency in demanding 24/7 environments. It offers durable caching with over 375,000/70,000 4K random read/write IOPS1 and a 988 TBW endurance rating2, suitable for multimedia post-production and database applications.

Consistently fast caching for 24/7 environments

Data integrity safeguards

Synology SNV3000 series integrates end-to-end data protection to safeguard data integrity over the entire transfer path. The SNV3500 comes with power loss protection circuit design3, further preventing data corruption during an abnormal shutdown: Dedicated capacitors provide power to flush data-in-flight into NAND flash in a power loss event and firmware is designed to enable a correct restart on the next power-up.

black mask
Data integrity safeguards
SNV3400 Series
SNV3500 Series

Lifetime analytics based on actual workload

Full integration with Synology’s DiskStation Manager (DSM) enables lifetime analytics for each SNV3000 series unit based on actual workloads4:

Timely Notifications

Plan further ahead for uninterrupted system performance and longevity with timely notifications.

Optimal Use

Easy monitoring allows you to make optimal use of each SSD.

Lifetime analytics based on actual workload
One-click firmware upgrades

One-click firmware upgrades

Automatic firmware update notifications and one-click installation through DSM minimize maintenance workload and reduce the chance of oversights.4

Purpose-built for Synology NAS

Purpose-built for Synology NAS

Synology SNV3000 series is thoroughly tested for compatibility with our systems following each engineering change, while firmware and component changes are strictly managed. Intensive I/O stress, power cycling, and temperature trials ensure that all products meet our strictest standards for quality and reliability.

Choose your SSD cache setup

NAS with built-in M.2 SSD slots

New Plus Series product line

New Plus Series product line
  • Accelerate I/O responsiveness with two built-in M.2 NVMe SSD slots
  • Average 15% performance boost to computing-intensive applications thanks to new CPU
  • Flexibly scale storage capacity according to your needs
M.2 SSD & 10GbE combo adapter card

E10M20-T1

E10M20-T1 mobile version
  • 1 x 10GBASE-T, 2.5/5GbE compliant
  • 2 x M.2 2280/22110 NVMe SSD slots
  • PCIe 3.0 x8
E10M20-T1 desktop version
M.2 SSD adapter card

M2D20

M2D20 mobile version
  • 2 x M.2 2280/22110 NVMe SSD slots
  • PCIe 3.0 x8
M2D20 desktop version

Notes:

  1. Performance was measured using FIO on Linux with Queue Depth 256 (4 KB = 4,096 bytes).

  2. The endurance rating was calculated based on a JESD219A enterprise workload.

  3. Power loss protection circuit design is available on SNV3500 to further prevent data corruption in case of power failure.

  4. DSM version requirement: 6.2.3-25426 or later version

  5. Power loss protection circuit design is available on SNV3500 Series to further prevent data corruption in case of power failure.

SNV3400
Hardware Specifications
SNV3410-400G
SNV3410-800G
General
Capacity 400 GB 800 GB
Form Factor M.2 2280 M.2 2280
Interface NVMe PCIe 3.0 x4 NVMe PCIe 3.0 x4
Performance
Sustained Sequential read (128 KB, QD32) 3,000 MB/s 3,100 MB/s
Sustained Sequential write (128 KB, QD32) 750 MB/s 1,000 MB/s
Sustained Random Read (4KB, QD256) 225,000 IOPS 400,000 IOPS
Sustained Random Write (4KB, QD256) 45,000 IOPS 70,000 IOPS
Notes
  • All performance measurement were reached in full sustained mode based on the JESD219A enterprise workload, defined by JEDEC Solid State Technology Association.
  • Performance specifications refer to SSD performance only. Actual performance may vary depending on the hardware and software configuration of the host system.
  • All performance measurement were reached in full sustained mode based on the JESD219A enterprise workload, defined by JEDEC Solid State Technology Association.
  • Performance specifications refer to SSD performance only. Actual performance may vary depending on the hardware and software configuration of the host system.
Endurance and Reliability
Terabytes Written (TBW)* 491 TB 1,022 TB
Warranty* 5 Years 5 Years
Notes
  • Based on the JESD219A enterprise workload.
  • 5-year limited warranty provides coverage until the end of the warranty period or until the endurance usage of the drive has been reached, whichever comes first. (Learn more)
  • Based on the JESD219A enterprise workload.
  • 5-year limited warranty provides coverage until the end of the warranty period or until the endurance usage of the drive has been reached, whichever comes first. (Learn more)
Power Consumption
Active Read (Typ.) 3.5 W 5.5 W
Active Write (Typ.) 3.3 W 4.6 W
Idle 1.6 W 1.6 W
Notes
 Power consumption may differ according to configurations and platforms. Power consumption may differ according to configurations and platforms.
Temperature
Operating Temperature 0°C to 70°C (32°F to 158°F) 0°C to 70°C (32°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F) -40°C to 85°C (-40°F to 185°F)
Compatibility
Applied Models
SNV3400
Hardware Specifications
SNV3410-400G
SNV3410-800G
General Capacity 400 GB 800 GB
Form Factor M.2 2280 M.2 2280
Interface NVMe PCIe 3.0 x4 NVMe PCIe 3.0 x4
Performance Sustained Sequential read (128 KB, QD32) 3,000 MB/s 3,100 MB/s
Sustained Sequential write (128 KB, QD32) 750 MB/s 1,000 MB/s
Sustained Random Read (4KB, QD256) 225,000 IOPS 400,000 IOPS
Sustained Random Write (4KB, QD256) 45,000 IOPS 70,000 IOPS
Notes
  • All performance measurement were reached in full sustained mode based on the JESD219A enterprise workload, defined by JEDEC Solid State Technology Association.
  • Performance specifications refer to SSD performance only. Actual performance may vary depending on the hardware and software configuration of the host system.
Endurance and Reliability Terabytes Written (TBW)* 491 TB 1,022 TB
Warranty* 5 Years 5 Years
Notes
  • Based on the JESD219A enterprise workload.
  • 5-year limited warranty provides coverage until the end of the warranty period or until the endurance usage of the drive has been reached, whichever comes first. (Learn more)
Power Consumption Active Read (Typ.) 3.5 W 5.5 W
Active Write (Typ.) 3.3 W 4.6 W
Idle 1.6 W 1.6 W
Notes Power consumption may differ according to configurations and platforms.
Temperature Operating Temperature 0°C to 70°C (32°F to 158°F) 0°C to 70°C (32°F to 158°F)
Storage Temperature -40°C to 85°C (-40°F to 185°F) -40°C to 85°C (-40°F to 185°F)
Compatibility
Applied Models
