DiskStation DS416slim

Miniature in size, powerful in performance

Mini NAS with comprehensive capabilities

Your own personal private cloud in the palm of your hands. DS416slim might be diminutive in size at less than 2.5 liters, but it packs comprehensive file management capabilities with versatile dual LAN ports and hot swappable trays for maximum service continuity.

Download Datasheet

CPU

Dual-core 1.0GHz

Ultra Performance

Up to 223 MB/s reading and 77 MB/s writing performance

Small Form Factor

Ultra-compact, portable design with hot-swappable trays

Network

Dual 1GbE LAN ports for failover and Link Aggregation

Compact size and eco-friendly

DS416slim is specially designed to fit in four 2.5-inch drives for flexible drive management. The small server consumes only 17W during operation, leaving lesser carbon footprint than traditional 4-bay NAS counterparts. Quiet and smaller than your palm, DS416slim easily blends into your environment.

Synology Hybrid RAID (SHR) technology

Storage management is easy with Synology Hybrid RAID (SHR) technology. SHR is an automated RAID management system allowing you to easily create and expand storage volumes and migrate RAID types without requiring details on RAID. SHR provides 1 to 2-disk redundancy to safeguard your data during drive failures.

Cost-effective

SHR maximizes the data capacity of your RAID when different sizes of HDDs are used. Calculate your RAID needs.

Easy Management

For novice users who have no technical background and still want to protect their data using RAID technology, a convenient installation wizard will guide you through all the steps during your first installation.

Scalability

You can add new disks on the fly in Storage Manager with a simple click. Learn more about SHR.

Flexibility

While creating a volume, you can plan ahead and leave empty and unallocated space for future usage.

Stream content to your TV

Turn your Synology NAS into a home media hub and stream your digital contents to computers, mobile devices, Samsung TV, Apple TV, Google Chromecast, and DLNA devices.

Easy file access with QuickConnect

Access files on your Synology NAS over the Internet without the hassle of setting up port forwarding rules, DDNS, or other complicated network settings. QuickConnect allows you to connect via a secure, customizable address, so that you can instantly access media and work files on any Internet-connected device at no additional charge.

Powered by Synology DSM

Synology Office

Collaborate on documents, spreadsheets, and slides in real time to boost team productivity.

Learn more

Desktop Backup

Simplified backup solution for your Mac, PC, and mobile devices.

Learn more

File Server/Management

Powerful built-in file management and sharing services.

Learn more

DSM UI

Award-winning operating system with an intuitive user interface and powerful capabilities.

Learn more

Security

Comprehensive built-in security tools are constantly updated to protect your devices against evolving threats.

Learn more

Multimedia

Complete multimedia solution for management, streaming, and playback.

Learn more
  • 1 LAN indicator
  • 2 Drive status indicator
  • 3 USB 3.0 port
  • 4 Status indicator
  • 5 Power indicator
  • 6 Power button
  • 7 USB 3.0 port
  • 8 1GbE RJ-45 port
  • 9 Reset button
  • 10 Power port
  • 11 Drive tray
  • 12 Kensington Security Slot

Hardware Specifications

CPU

CPU

CPU Model Marvell Armada 385 88F6820
CPU Architecture 32-bit
CPU Frequency Dual Core 1.0 GHz
Hardware Encryption Engine

Memory

Memory

System Memory 512 MB DDR3
Notes Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Storage

Storage

Drive Bays 4
Compatible Drive Type* (See all supported drives)
  • 2.5" SATA HDD (up to 12.5 mm drive height)
  • 2.5" SATA SSD
Maximum Internal Raw Capacity 8 TB (2 TB drive x 4) (Capacity may vary by RAID types)
Maximum Single Volume Size* 16 TB
Hot Swappable Drive
Notes
  • "Compatible drive type" indicates the drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
  • The maximum single volume size is not directly related to the maximum raw capacity. (Learn more)

External Ports

External Ports

RJ-45 1GbE LAN Port 2 (with Link Aggregation / Failover support)
USB 3.0 Port 2

File System

File System

Internal Drives
  • EXT4
External Drives
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+*
  • exFAT*
Notes
  • HFS+ is read only, max 2TB volume size.
  • exFAT Access is purchased separately in Package Center.

Appearance

Appearance

Size (Height x Width x Depth) 120 mm x 105 mm x 142 mm
Weight 0.66 kg

Others

Others

System Fan 60 mm x 60 mm x 1 pcs
Fan Speed Mode
  • Cool Mode
  • Quiet Mode
  • Low-power Mode
Easy Replacement System Fan
Brightness Adjustable Front LED Indicators
Power Recovery
Noise Level* 20.3 dB(A)
Scheduled Power On / Off
Wake on LAN / WAN
Power Supply Unit / Adapter 30 W
AC Input Power Voltage 100 V to 240 V AC
Power Frequency 50/60 Hz, Single Phase
Power Consumption* 17.17 W (Access)
11.63 W (HDD Hibernation)
British Thermal Unit 58.63 BTU/hr (Access)
39.71 BTU/hr (HDD Hibernation)
Notes
  • Power consumption is measured when it's fully loaded with Western Digital 1TB WD10JFCX hard drive(s).
  • Noise Level Testing Environment: Fully loaded with WD 1TB WD10JFCX hard drive(s) in the idle state. Two G.R.A.S. Type 40AE microphones, each set up 1 meter away from the Synology NAS at the front and rear. Background noise: 17.2 dB(A); Temperature: 23.6˚C; Humidity: 58.2%.

Temperature

Temperature

Operating Temperature 5°C to 40°C (40°F to 104°F)
Storage Temperature -20°C to 60°C (-5°F to 140°F)
Relative Humidity 5% to 95% RH

Certification

Certification

  • EAC
  • CCC
  • RCM
  • KC
  • FCC
  • CE
  • BSMI

Warranty

Warranty

2 Years
Notes The warranty period starts from the purchase date as stated on your purchase receipt. (Learn more)

Environment

Environment

RoHS Compliant

Packaging Content

Packaging Content

  • Main Unit X 1
  • Welcome Note X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • RJ-45 LAN Cable X 2

Optional Accessories

Optional Accessories

  • Surveillance Device License Pack
  • VS360HD
  • VS960HD

DSM Specifications

Storage Management

Storage Management

Maximum Internal Volume Number 64
Maximum iSCSI Target Number 10
Maximum iSCSI LUN 10
Supported RAID Type
  • Synology Hybrid RAID
  • Basic
  • JBOD
  • RAID 0
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
RAID Migration
  • Basic to RAID 1
  • Basic to RAID 5
  • RAID 1 to RAID 5
  • RAID 5 to RAID 6
Volume Expansion with Larger HDDs
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5
  • RAID 6
  • RAID 10
Volume Expansion by Adding a HDD
  • Synology Hybrid RAID
  • JBOD
  • RAID 5
Global Hot Spare Supported RAID Type
  • Synology Hybrid RAID
  • RAID 1
  • RAID 5

File Services

File Services

File Protocol CIFS/AFP/NFS/FTP/WebDAV
Maximum Concurrent CIFS/AFP/FTP Connections 100
Windows Access Control List (ACL) Integration
NFS Kerberos Authentication

Account & Shared Folder

Account & Shared Folder

Maximum Local User Accounts 1,024
Maximum Local Groups 256
Maximum Shared Folder 256
Maximum Shared Folder Sync Tasks 2

Log Center

Log Center

Syslog Events per Second 100

General Specifications

General Specifications

Networking Protocols SMB1 (CIFS), SMB2, SMB3, NFSv3, NFSv4, NFSv4.1, NFS Kerberized sessions, iSCSI, HTTP, HTTPs, FTP, SNMP, LDAP, CalDAV
Supported Browsers
  • Chrome
  • Firefox
  • Edge
  • Internet Explorer 10 onwards
  • Safari 10 onwards
  • Safari (iOS 10 onwards)
  • Chrome (Android 6.0 onwards)
Supported Language English, Deutsch, Français, Italiano, Español, Dansk, Norsk, Svenska, Nederlands, Русский, Polski, Magyar, Português do Brasil, Português Europeu, Türkçe, Český, ภาษาไทย, 日本語, 한국어, 繁體中文, 简体中文

Add-on Packages view the complete package list

Synology Chat

Synology Chat

Maximum Users 10
Notes
  • The number of concurrent HTTP connections for Synology Chat was configured to the maximum.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • For tested models with expandable memory, the maximum amount of RAM was installed.

Cloud Station Server

Cloud Station Server

Recommended Number of Hosted Files 100,000
Recommended Number of Concurrent Sync Clients 128 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • The maximum number of concurrently connected devices refers to the maximum number of devices that can remain connected at the same time.
  • The maximum number of hosted files refers to the maximum number of files that can be indexed and hosted by the Cloud Station Server service. RAM expansion was not used during testing.
  • Non-encrypted shared folders were used during the aforementioned testing.

Download Station

Download Station

Maximum Concurrent Download Tasks 50

exFAT Access (Optional)

exFAT Access (Optional)

Media Server

Media Server

DLNA Certification

Moments

Moments

Facial Recognition

Surveillance Station

Surveillance Station

Maximum IP cam (Licenses required) 8 (including 2 Free License) (See All Supported IP Cameras)
Total FPS (H.264)* 240 FPS @ 720p (1280x720)
150 FPS @ 1080p (1920x1080)
100 FPS @ 3M (2048x1536)
40 FPS @ 5M (2591x1944)
Total FPS (MJPEG)* 150 FPS @ 720p (1280x720)
75 FPS @ 1080p (1920x1080)
50 FPS @ 3M (2048x1536)
25 FPS @ 5M (2591x1944)
Notes Surveillance Station throughput is tested with Axis network camera, using continuous recording with live view from Surveillance Station and motion detection by camera. Live view and recording are sharing the same stream from the camera.

Synology Drive

Synology Drive

Recommended Number of Hosted Files 100,000 (applies to files indexed or hosted by Synology Drive. For file access through other standard protocols, refer to the File Services section above)
Recommended Number of Concurrent Sync Clients 200 (the number of connections that can be maintained when the recommended number of hosted files was reached)
Notes
  • Exceeding the limits above may result in longer response time in file operations.
  • EXT4 file system and non-encrypted shared folders were used during the aforementioned testing.

Synology Office

Synology Office

Maximum Users 100
Notes
  • Multiple files were opened for testing and each file was edited by 30 users simultaneously.
  • CPU and RAM usage were both under 80% when the number of maximum users was reached.
  • Client performance may affect maximum simultaneous editing users. Client PCs used for testing: Intel Core i3-3220 / 8GB RAM

Video Station

Video Station

Video Transcoding Group 2 (See more)

VPN Server

VPN Server

Maximum Connections 10

Notes:

  • Model specifications are subject to change without prior notice.
